OEM ODM LiFePO4 high voltage marine boat lithium battery 530v 230ah 120kwh IP67 waterproof with liquid cooling for marine

مقدار حداقل تعداد سفارش : 2 واحد قیمت : قابل مذاکره
جزئیات بسته بندی : مورد چوبی و پرونده کارتن زمان تحویل : 7-15 روز کاری
شرایط پرداخت : T/T قابلیت ارائه : 10000 واحد در ماه
محل منبع: هونان ، چین نام تجاری: Chalong Fly
گواهی: CE,ROHS,FCC,IEC62133,MSDS,UN38.3, UL, etc شماره مدل: CLFLE218

اطلاعات تکمیلی

نوع باتری:: باتری LifePo4 ولتاژ:: 96 ولت
ظرفیت:: 300ah اندازه:: سفارشی
OEM/ODM:: بله بسته حمل و نقل:: مورد فوم و تخته سه لا
استاندارد ضد آب:: IP67 کد HS:: 8507600090
ویژگی ها:: مقرون به صرفه، تحویل سریع، ساختار پایدار برنامه:: وسیله نقلیه الکتریکی، قایق برقی، قایق بادبانی برقی، دریایی

توضیحات محصول

OEM ODM LiFePO4 30kwh marine battery pack 96V 300Ah lifepo4 battery for electric boat



If you don't see any products that are matching your requirements please contact us. We may not have it listed on our website yet.



Chalong fly provides ODM&OEMs with assurances of quality for our products and our services. We distribute battery packs and battery cells from many reputable brand names. We manufacture a variety of custom battery packs and power supplies made to customer specifications.





OEM ODM LiFePO4 high voltage marine boat lithium battery 530v 230ah 120kwh IP67 waterproof with liquid cooling for marine 0OEM ODM LiFePO4 high voltage marine boat lithium battery 530v 230ah 120kwh IP67 waterproof with liquid cooling for marine 1

Product Parameter
MODEL
96300
Cell Type - Chemistry
Prismatic- LiFePO4
Rated Capacity
304Ah
Rated Voltage
96V
Energy
29.18KWh
Resistance
30mΩ
Self Discharge
<3% per month
PDU
BMS, 400A relays, fuses, COM socket
Dimensions (L x W x H)
L1300*W500*H380mm
(Can make it smaller if you want)
Weight
2540Kg
Enclosure Protection
IP67 stainless steel case
Discharge Cut-off Voltage
75V
Max Continuous Discharging Current
300A
Peak Discharge Current
400A for 60 seconds
Recommended Discharge Current
300A
Charging Limited Voltage
109.5V
Max Charging Current
200A
Recommended Charge Current
100A
Charge Temperature Range
0~50℃
Discharge Temperature Range
-20~60℃
Recommended Operating Temperature
15~35℃
Available on request
Size, C rate, Communication protocol



OEM ODM LiFePO4 high voltage marine boat lithium battery 530v 230ah 120kwh IP67 waterproof with liquid cooling for marine 2OEM ODM LiFePO4 high voltage marine boat lithium battery 530v 230ah 120kwh IP67 waterproof with liquid cooling for marine 3OEM ODM LiFePO4 high voltage marine boat lithium battery 530v 230ah 120kwh IP67 waterproof with liquid cooling for marine 4

Optional thermal management system
liquid cooling and heating system can adapt the battery to different working environment
temperatures .Battery thermal management systems are designed to regulate the temperature of batteries in electric vehicles or other battery-powered systems. It is good in maintaining the overall health and performance of batteries. that helps maintain the optimal temperature to ensure optimal battery performance.

OEM ODM LiFePO4 high voltage marine boat lithium battery 530v 230ah 120kwh IP67 waterproof with liquid cooling for marine 5OEM ODM LiFePO4 high voltage marine boat lithium battery 530v 230ah 120kwh IP67 waterproof with liquid cooling for marine 6OEM ODM LiFePO4 high voltage marine boat lithium battery 530v 230ah 120kwh IP67 waterproof with liquid cooling for marine 7

OEM ODM LiFePO4 high voltage marine boat lithium battery 530v 230ah 120kwh IP67 waterproof with liquid cooling for marine 8OEM ODM LiFePO4 high voltage marine boat lithium battery 530v 230ah 120kwh IP67 waterproof with liquid cooling for marine 9OEM ODM LiFePO4 high voltage marine boat lithium battery 530v 230ah 120kwh IP67 waterproof with liquid cooling for marine 10OEM ODM LiFePO4 high voltage marine boat lithium battery 530v 230ah 120kwh IP67 waterproof with liquid cooling for marine 11OEM ODM LiFePO4 high voltage marine boat lithium battery 530v 230ah 120kwh IP67 waterproof with liquid cooling for marine 12OEM ODM LiFePO4 high voltage marine boat lithium battery 530v 230ah 120kwh IP67 waterproof with liquid cooling for marine 13OEM ODM LiFePO4 high voltage marine boat lithium battery 530v 230ah 120kwh IP67 waterproof with liquid cooling for marine 14OEM ODM LiFePO4 high voltage marine boat lithium battery 530v 230ah 120kwh IP67 waterproof with liquid cooling for marine 15OEM ODM LiFePO4 high voltage marine boat lithium battery 530v 230ah 120kwh IP67 waterproof with liquid cooling for marine 16



FAQ:

Q1. Are you a factory?

A: Yes, we are a professional lithium battery manufacturer in China, and factory tour is acceptable.



Q2. Do you accept OEM/ODM?

A: Yes, OEM, ODM, LOGO, and STICKER is acceptable, our professional team is on hand to offer you any solutions.



Q3. Can I have a sample order first?

A: Yes, sample order is acceptable.



Q4. How will my order be shipped?

A: Chalong Fly offers a variety of shipping methods, such as DHL, UPS, FedEx, TNT, Airline and sea shipping.



Q5: What kind of certificates do you have?

A: We can provide CE,ROHS,FCC,IEC62133,MSDS,UN38.3, UL, etc.



Q6. Can we sign a NDA in order for a long-term cooperation?

A: Yes, the client’s requirements is respected.



O7: Is there any warranty or After-Sale Service?

A: We will check each battery before shipment, and 100% high quality guaranteed. The warranty is about 1~20 years depends on different models.



Q8. Why do you choose Chalong Fly?

A: Chalong Fly R&D center has more than 60 R&D engineers, 12 of whom have more than 10 years of experience related to power development. We have a deep understanding of power electronics technology, and a full understanding of the needs of the application industry, and have developed many public technology solutions.
